Advanced E-type Low-voltage Watt-hour Meter
A - type
Dimensions
| A | B | C | D | |
|---|---|---|---|---|
| SIZE (mm) | 137 | 190.8 | 75 | 133.5 |
Parameters
| Model | Phase·Wire | V | A | Hz | Pulse·kWh | Class | Etc |
|---|---|---|---|---|---|---|---|
| PS12DR050E | 1P2W | 220 | 50 (5) | 60 | 1,000 | 1.0 | Outdoor Installation |
B - type
Dimensions
| A | B | C | D | |
|---|---|---|---|---|
| SIZE (mm) | 137 | 158.2 | 75 | 133.5 |
Parameters
| Model | Phase·Wire | V | A | Hz | Pulse·kWh | Class | Etc |
|---|---|---|---|---|---|---|---|
| PS12DR050E | 1P2W | 220 | 50 (5) | 60 | 1,000 | 1.0 | Outdoor Installation |
