Features

• Industrial Metering Data 1

  Active Power Consumption, Lagging·Leading Reactive Power, Apparent Power, Maximum Demand Power, Power Factor

• Various External Control Signals Provided

  Load Switching, EQI, and External Pulse Output Functions

• Industrial Rate Plan selectable

  Time-of-Use(4 types of TOU) selection function, with precise built-in time and calendar

• Self-diagnosis and Event Information

  Event Transmission Functions for Memory, Battery, Neutral Line Miswiring, Reverse Metering, Voltage Imbalance, etc.

• International Comm. Protocol

  Metering data transmitted through KEPCO High-voltage Standard Protocol via Optical Communication Interface

• Improved Data Reliability

  Power outage detection and battery monitoring functions prevent data loss during outages, and non-volatile memory ensures data retention for over 10 years

• Demand Management Data

  Maximum Demand Power Block & Rolling Interval (1, 5, 10, 15, 30, 60 minutes), LP (Load Profile)

• Power Quality Information

  Per-phase Voltage (V), Current (A), Phase Angle (º), THD (Total Harmonic Distortion), Frequency (Hz), Power Factor (PF)
