NIU
Dimensions
| A | B | C | D | |
|---|---|---|---|---|
| SIZE (mm) | 136 | 112 | 36 | 93 |
Specifications and Standards
| Items | Specifications and Standards | ||
|---|---|---|---|
| Model Name | PNU -20 | ||
| Rated Voltage | DC 5V (Adapter) | ||
| Power Consumption | 2.5W max | ||
| RS 485 | Communication Range | Within 500m of household unit | |
| Within 1km of server | |||
| Connectable Households | 200 Households | ||
| Communication Line | Single Twisted Pair | ||
| Communication Speed | B/W Residential Units | 960bps | |
| B/W Servers | 1,200 ~ 115,200bps (9600bps default) | ||
| Communication Protocol | PTS Proprietary Protocol | ||
| Ethernet | Standard | IEEE 802.3 | |
| Network Interface | 10 base - T / 100 base - TX | ||
| Ethernet Speed Auto Sense | |||
| 1:1 or Cross-over cable Auto Sense | |||
| Network Protocol | TCP / UDP / IPc4 / APR | ||
| Communication Mode | TCP Server | ||
| Connector | RJ45 | ||
| Cable Specifications | Cat.5 UTP / STP | ||
| Certification | KC (Electromagnetic Compatibility for Broadcasting and Communication Equipment) | ||
| Operating Conditions | -20 ~ 60 | ||
| Warranty Period | 2 years | ||
Features
Collect and manage energy usage for up to 200 households per device
Selectable communication methods: PS-485 or Ethernet
LCD for data display
RS-485 communication port provided for integration with other systems
Fault diagnosis for communication status, data storage status etc.
